LIGHTS SOLD EACH
CHECK OUT ALL THE NEW FEATURES
- New robust aluminium one-piece housing
- Increased surface area for better heat management
- Slimline design to fit most modern bullbars
- Profile compatible with more frontal crash avoidance systems
- Modular spot, combo, & amber filters, and black covers available
- More efficient, true 5000K OEM spec Phillips® D1S HID bulb
- Reliable German OEM spec Osram® ballast for reduced EMI
- Shielded cables surpassing EMC compliance with CE certification
- Redesigned seals including a fully integrated waterproof plug
- Superior ingress protection surpassing IP68 and IP69K level
- New pre-treatment and UV stabilised powder coated finish
- Repositioned mounting point with redesigned captive Nyloc® nuts
- Improved balance, rigidity and strength
- Easy access point for simple HID bulb replacement
PLUS THE HTX’S ORIGINAL PROVEN FEATURES
- Twenty domeless 5000K Lumileds® Luxeon ZES LEDs
- Superior performance and reduced glare
- The combination of HID and LED offers amazing performance
- 1 Lux at over 1,650 metres and .25 Lux at over 3,200 metres
- CRI of 70 plus for better colour rendering and less eye fatigue
- Genuine Gore® waterproof membrane with mechanical seal
- Reversible robust mounting base as proven across our LED range
- Over, under and reverse voltage and thermal overload protection
- Comprehensive installation instructions for easy DIY installation
SPECIFICATIONS
| Globe Type | LED|HID |
|---|---|
| Distance: 1 lux at | 1650m (Pair) |
| Distance: 0.25 lux at | 3,300m (Pair) |
| Effective Lumens | 8050 |
| Raw Lumens | 8400 |
| Colour Temperature | 5000K |
| CRI | 70 |
| Current Draw | 11.5Amps @ 12V | 6AMP @24V |
| Voltage | 18V – 30V |
| Wattage | 130W |
| Ingress Protection Rating | IP68 and IP69K |
| Diameter | 230mm |
| Weight | 2.3kg including bracket |
